Aeotec

Pico Switch (Zigbee)

Regular price $44.99 $0.00 Unit price per
Shipping calculated at checkout.

Aeotec Pico Switch is retrofitable inwall switch to control and read the energy consumptions of sockets or lights via Zigbee, upgradable to Thread and matter ready products.

Features:

  • Easy installation thanks to spring terminals
  • High security with latest DIN EN60669 certification
  • Power metering
  • Automatic switch recognition
  • Scene controller function
  • Works with SmartThings Edge integration for local automations
  • Zigbee 3.0 and Touchlink function
  • Over current and heat protection
  • Acts as a Zigbee signal repeater

Technical Specs:

  • Zigbee Hardware: EFR32MG21
  • Zigbee 3.0 Repeater: Yes
  • Zigbee Backward Compatibility: ZHA, ZLL
  • Zigbee Profile: 0x0104 (Home Automation)
  • Max Signal Strength: 17.02 dBm
  • Device max. Power Consumption: 1 W Power Rating: 110-230V~, 50/60Hz
  • Supported Switch Types: Momentary (NC/NO); 2-Way Switch; SPDT Switch
  • Max Current: Resistive – 16A (EU); Capacitive - 10A@cosΦ = 0.75~0.80; Inductive - 3.6A, 1/3HP each output
  • Built-in: Overheat protection, Surge Protection, Temperature Sensor
  • Operating Temperature: 32°F to 104°F/0°C to 40°C.
  • Relative Humidity: 8% to 80%.
  • Operating Distance: More than 50 meters indoors. Up to 100 meters outdoors.



More information:

User guide  Tech. Specs.
